| 项目/Item | 名称/Name | 单位/ Unit | YKJ-80 |
| 核心性能 Core Performance |
单次循环工作时间 Single Cycle Working Time |
秒 /s | 约 60（不含上下料） About 60 (excluding loading & unloading) |
| 设备控制方式 Control Mode |
- | 手动操作阀 Manual Operation Valve |
|
| 液压系统 Hydraulic System |
主压油缸 Main Press Cylinder |
数量：1，行程：300mm | |
| Quantity: 1, Stroke: 300mm | |||
| 侧压油缸 Side Press Cylinder |
- | 数量：1，行程：400mm | |
| Quantity: 1, Stroke: 400mm | |||
| 门盖油缸 Door Cover Cylinder |
数量：1，行程：560mm | ||
| Quantity: 1, Stroke: 560mm | |||
| 翻包油缸 Bale Turning Cylinder |
- | 数量：1，行程：300mm | |
| Quantity: 1, Stroke: 300mm | |||
| 液压系统工作压力 Hydraulic System Working Pressure |
MPa | 20 | |
| 液压泵额定压力 Hydraulic Pump Rated Pressure |
MPa | 31.5 | |
| 液压泵排量 Hydraulic Pump Displacement |
ml/r | 40.0 | |
| 液压泵数量 Hydraulic Pump Quantity |
台 / Set | 1 | |
| 液压泵型号 Hydraulic Pump Model |
MCY40 | ||
| 料箱与包块规格 Hopper & Bale Specification |
压缩式料箱规格 Compression Hopper Size |
mm | 500*400*250 |
| 成品包块截面尺寸 Finished Bale Section Size |
mm | 100*100 | |
| 包块可调长度 Bale Adjustable Length |
mm | 300 | |
| 驱动系统 Drive System |
驱动电机额定功率 Drive Motor Rated Power |
KW | 11 |
| 驱动电机额定转速 Drive Motor Rated Speed |
r/min | 960 | |
| 驱动电机数量 Drive Motor Quantity |
台 / Set | 1 | |
| 电动机型号 Drive Motor Model |
Y2-250M-6 | ||
| 设备通用规格 General Specification |
设备外形尺寸 Overall Dimensions |
mm | 1800*1400*1000 |
| 适用电源规格 Power Supply |
V-HZ | 380-60 |
